Intensified cameras enable full-field frequency-domain and time-domain FLIM. The image intensifier becomes an ultra-fast electro-optical shutter by operating it at radio frequencies allowing time-resolved imaging. The high-resolution image intensifier is the key component of the TRiCAM (part of the LIFA) and the TRiCATT camera attachment. Its photon gain is typically in the range of 100 to 10000. Lambert Instruments provides different image intensifiers based on photocathodes with different spectral sensitivity to match a range of applications in the UV, visible and NIR.
For FLIM in the lifetime range of 0 ps to 1 ms we provide S20 (UV) and SuperS25 (visual) image intensifiers. For increased quantum efficiency of the photocathode in the visual part of the spectrum in this lifetime range, a GaAs intensifier is available. For near-infrared applications up to about 1100 nm an InGaAs photocathode is available.
The graph below shows the spectral sensitivity of these photocathodes.
